Tern
Short Haul D8
Please Call Before Ordering
Pickup available at 815 Christchurch Road
Usually ready in 5+ days
Shipping & Returns
- We offer shipping up to 100 miles.
- Please contact the store if you require assistance with delivery.
Pickup available at 815 Christchurch Road
Usually ready in 5+ days
Shipping & Returns
- We offer shipping up to 100 miles.
- Please contact the store if you require assistance with delivery.
Product Specification
Take a look at the specifications of the Short Haul D8:
General Info
• Speeds: 1 x 8
• Weight: 16.1 kg (35.5 lb)
• Gear Inches: 31" - 95" (2.45 - 7.57 m)
• Frame Sizes: One size
• Distance: Seatpost to Handlebar: 60 - 64 cm (23.6 - 25.2 in)
• Distance: Saddle to Pedal: 62 - 110 cm (24.4 - 43.3 in)
• Suggested Rider Height: 147 - 190 cm (57.9 - 74.8 in)
• Max Gross Vehicle Weight: 140 kg (308.6 lb)
• Max Rider Weight: 120 kg (264.6 lb)
Frame & Forks
• Frame: Tern Short Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 140 kg
• Fork: Steel, EFBE approved: 140 kg
Cockpit
• Stem: Forged, 31.8
• Headset: TH, cartridge bearings
• Handlebar: Low riser, 31.8, 6061-AL
• Grips/Bar Tape: Velo ergonomic, lock-on
• Saddle: Velo Comfort
• Seatpost: 31.6 mm, 6061-AL, micro-adjust clamp
• Seatpost Clamp: Tern Collar
Transmission
• Shifter(s): 1 x 8 spd, trigger
• Rear Derailleur: Shimano Altus
• Crankset: Forged 6061-AL crankarm
• Cassette/Freewheel: 11-34T, 8 spd
• Bottom Bracket: FSA, Cartridge, sealed bearings
• Chain: KMC, 8 spd
• Pedals: Urban with non-slip surface
• Shifter Cable & Housing: SP
Wheelset
• Front Hub: Disc, aluminum
• Rear Hub: 8 spd, disc, aluminum
• Spokes & Nipples: Stainless steel
• Rims: Doublewall, for disc
• Tyres: Schwalbe Big Apple, 55-406, puncture protection, Reflex
Brakes
• Front Brake: Hydraulic disc
• Rear Brake: Hydraulic disc
• Brake Levers: Hydraulic disc
• Brake Cable & Housing: Hydraulic disc
Bells & Whistles
• Bell: Aluminum
• Chainguard: SKS Chainblade
• Kickstand: Pletscher design, rear mount
• Luggage Socket: Combo Mount
• Fenders: SplashGuard, stainless hardware
• Rack(s): Atlas Q Rack, 6 point mounting, Vertical Parking, 50 kg capacity
The kind of bike you'll find yourself
using every day!
Compact Cargo Bike
A compact cargo bike that makes it easy to get around town and get things done. Practical and uncomplicated, the Short Haul has everything the modern urban rider needs—and nothing that they don’t.
1x8 Shimano Altus
Rear Rack Capacity Of 50kg
Hydraulic disc brakes
⓵ Easy to Carry
Weighing in at 16.1 kg (35.4 lb), the Short Haul is one of the lightest cargo bikes around. A frame carry handle makes it even easier to lift the bike.
⓶ Front Cargo Capacity
The robust Combo Mount carries up to 20 kg (44 lb), and is compatible with a wide range of front racks, bags, and baskets.
⓷ Modular Accessories
Customize the Short Haul for the way you ride. School runs, doggy playdates, or some serious cargo hauling? We've got you covered.
