Tern
NBD S5I
Please Call Before Ordering
Pickup available at 815 Christchurch Road
Usually ready in 5+ days
Shipping & Returns
- We offer shipping up to 100 miles.
- Please contact the store if you require assistance with delivery.
Pickup available at 815 Christchurch Road
Usually ready in 5+ days
Shipping & Returns
- We offer shipping up to 100 miles.
- Please contact the store if you require assistance with delivery.
Product Specification
Take a look at the specifications of the NBD S5I:
General Info
• Speeds: 1 x 5
• Weight: 23.4 kg (51.6 lb)
• Gear Inches: 34" - 90" (2.75 - 7.22 m)
• Folding Size: 38 × 156 × 79 cm (15 × 61.4 × 31.1 in)
• Folding Time: 5 sec
• Frame Sizes: One size
• Distance: Seatpost to Handlebar: 45 - 52 cm (17.7 - 20.5 in)
• Distance: Saddle to Pedal: 70 - 100 cm (27.6 - 39.4 in)
• Suggested Rider Height: 147 - 190 cm (57.9 - 74.8 in)
• Max Gross Vehicle Weight: 140 kg (308.6 lb)
• Max Rider Weight: 120 kg (264.6 lb)
Frame & Forks
• Frame: Tern NBD, 6061-AL, Patented design, EFBE Tri-Test approved: 140 kg
• Fork: Tern Tarsus, 6061-AL, hydroformed, EFBE approved: 140 kg
Cockpit
• Handlepost: Tern Physis 3D, 3D forged, 5 patented technologies, 12°, 350 mm
• Stem: Tern Andros, adjustable, forged construction, patented technology
• Headset: Tern Flux by FSA, cartridge bearings, Physis integrated
• Handlebar: Tern Sweep, 6061-AL, Tern Andros adapted
• Grips/Bar Tape: Ergon
• Saddle: Tern Upright by Velo
• Seatpost: Tern RideEasy Suspension, 34.9 mm, Air cartridge, Preload adjustable
• Seatpost Clamp: Tern Collar
Transmission
• Shifter(s): Shimano 5 spd.
• Crankset: Tern NBD custom, Gates CDX CNC machined beltring
• Cassette/Freewheel: Gates CDX, precision CNC machined cog
• Chain: Gates Carbon Drive CDX belt
• Pedals: MKS Platform, Tern custom design
• Shifter Cable & Housing: Shimano
E-System
• Motor: Bosch Performance, 300% Assist, 65 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
• Battery: Bosch PowerPack 500
• Display: Bosch Intuvia, 4 mode selectable, walk assist
• Range: 51-118 km (32-74 mi)
• Charger: Bosch Standard Charger
Wheelset
• Front Hub: Shimano disc
• Rear Hub: Shimano Nexus INTER-5E
• Spokes & Nipples: Stainless steel
• Rims: Kinetix Comp, for disc
• Tyres: Schwalbe Big Apple, Performance Line, 55-406, puncture protection, Reflex
Brakes
• Front Brake: Magura MT4, hydraulic disc
• Rear Brake: Magura MT4, hydraulic disc
• Brake Levers: Magura, hydraulic
• Brake Cable & Housing: Magura, hydraulic
Bells & Whistles
• Bell: Aluminum
• Chainguard: Tern Custom, full chain cover
• Kickstand: Ursus, rear mount
• Luggage Socket: Combo Mount
• Front Light: Tern Valo Direct, 190 lumens
• Rear Light: Herrmans
• Fenders: SplashGuard, stainless hardware
• Rack(s): Gaia Rack, 27 kg capacity, Vertical Parking
• Frame Lock: ABUS, keyed-alike with Bosch battery
The welcoming low step e-bike
that's easy to ride and love
Perfectly Suited To All
Our most accessible bike yet, the NBD makes cycling No Big Deal. Maneuvering along streets while staying in balance is now second nature thanks to a low center of gravity that’s key to a super stable ride. Riders have maximum control and power at their feet to tackle any adventure that awaits.
Gates CDX Belt Drive
Bosch Active Line Plus motor
Rear Rack Capacity Of 27kg
⓵ Hassle-Free Belt Drive
Bike chains are great, but often need cleaning and lubing. The NBD S5i comes equipped with a Gates belt drive for durability, low maintenance and a smoother and quieter ride, so you can spend less time cleaning, and more time riding.
⓶ Smooth, Powerful Motor
The Bosch e-assist motor system is powerful, efficient, smooth, and supremely quiet. It’s also backed with best-in-class service and support, and a network of thousands of trained dealers in cities around the world.
⓷ RideEasy Suspension Seatpost
The custom short-stack suspension seatpost adjusts to fit riders of different heights, and allows even smaller sized riders to travel without feeling road vibrations.
